ZG3P PCB type AC SSR
Classification: Solid State Relay - Single-Phase Solid State Relay
ZG3P
|
Load Voltage |
220VAC or 380VAC |
|
Load Current |
3A，5A |
|
Control Voltage |
DC3-14V or DC3-32V |
|
Control Current |
6-35mA |
|
〇n Voltage |
≤1.2VAC |
|
〇ff-state Leakage Current |
≤1.5mA |
|
Time Off |
≤10ms |
|
Dielectric Strength |
1500VAC |
|
Insulation Resistance |
100MΩ/500VDC |
|
Ambient Temperature |
-25~+75℃ |
|
Mounting Methods |
PCB |
|
The work instructions |
/ |
|
Weight |
18g |
